9.2 I/O Signal List

586

Symbol

series

AddressSignal name

STRD Input and run simultaneous

mode select signal

G058#5 – f

STWD Output and run

simultaneous mode select

signal

G058#6 – f

SUCLP Spindle unclamp signal F038#1 f –

SVF1 to SVF8 Servo off signal G126 f f

SVWRN1 to 4 Servo warning detail signal F093#4 to

f f

SWS1 G027#0 f f

SWS2 G027#1 f f

SWS3

Spindle selection signal

G027#2 f f

SWS4 G026#3 f f

SYCAL Spindle synchronous

control alarm signal/

phase error monitor signal

F044#4 f f

SYN1O to

SYN8O

Synchronous control under

way signals

F118 f –

SYN1O to

SYN7O

Synchronous/composite/

superimposed control

under way signals

F118 F –

SYNC1 to

SYNC8

Simple synchronous axis

select signal

G138 f f

SYNC to

Synchronous control axis

G138 f –

SYNC8

Synchronous control axis

selection signals

G138 F –

SYNCJ1 to

SYNCJ8

Simple synchronous

manual feed axis select

signal

G140 – f

SYNMOD EGB mode signal F065#6 f

T00 to T31 Tool function code signal F026 to

F029

f f

TAP Tapping signal F001#5 f f

TF Tool function strobe signal F007#3 f f

TFIN Tool function completion

signal

G005#3 f f

THRD Thread cutting signal F002#3 f f

TIALM Tool post interference alarm

signal

F064#7 F –

TICHK Tool post interference

check signal

F064#6 F –

TL01 to TL64

Tool group number select

G047#0 to

f –

TL01 to TL256

Tool group number select

signal

G047#0 to

G048#0

– f

TLCH Tool change signal F064#0 f f

TLCHB Tool life arrival notice signal F064#3 – f

TLCHI Individual tool change

signal

F064#2 – f
