19. MAINTENANCE FUNCTION

925

(2) Select the file to be deleted.

1 Using the [UP] or [DOWN] soft key, position the cursor to the

desired file name.

2 Press the [SELECT] soft key.

D To quit and return to the SYSTEM MONITOR MAIN MENU

screen, position the cursor to END, then press the [SELECT]

soft key.

3 A confirmation message appears at the bottom of the screen. To

delete the file, press the [YES] soft key. To abandon the deletion,

press the [NO] soft key.

Upon pressing the [YES] soft key, the specified file is deleted.

³ Once the file has been deleted, “HIT SELECT KEY” appears

at the bottom of the screen.

(3) Press the [SELECT] soft key to return to the SYSTEM DATA CHECK

screen.

19.3.5 Output

F Saving a FROM file to a memory card

(SYSTEM DATA SAVE screen)

NOTE Only user files, such as the ladder and macro P-code programs,

can be saved to a memory card. System files, such as NC BASIC,

cannot be saved.

(1) Select the SYSTEM DATA SAVE screen.

1 Using the [UP] or [DOWN] soft key, position the cursor to 4.

SYSTEM DATA SAVE.

2 Press the [SELECT] soft key.

When more than one board is connected to the NC, the SLOT

CONFIGURATION screen appears.

³ FROM files are listed on the screen as follows:

SELECT

[][][][][]

YES NO UP DOWN

***MESSAGE***

SELECT FILE AND HIT SELECT KEY.

SYSTEM DATA SAVE

[ BOARD : MAIN ]

FILE DIRECTORY

1. NC BASIC (10)

2. NC2 BAIC (8)

3. DGB0SRVO (2)

4. PS0B406G (8)

5. PS1B406G (4)

6. PS2B406G (4)

7. ETH2 EMB (8)

8. PMC–SB (1)

END

(2) Select the file to be saved.

1 Using the [UP] or [DOWN] soft key, position the cursor to the

desired file name.

2 Press the [SELECT] soft key.

D To quit and return to the SYSTEM MONITOR MAIN MENU

screen, position the cursor to END, then press the [SELECT]

soft key.
