13. DIAGNOSIS INFORMATION

773

Supplement 3 : About the functions indicated in the column of Action

For the following functions indicated in the table, refer to “FANUC AC SERVO

MOTOR αi series Parameter Manual (B–65270EN)”:

D Function for changing the internal format of the velocity loop proportional gain

D Position gain expansion function

D Vibration–damping control function

D Runaway detection function

355

Communication alarm ignore counter (separate)

DGN

356

Connection processing counter (built–in)

DGN

357

Connection processing counter (separate)

DGN

The number of communication errors that occur in serial communication with

the detector is indicated. As long as no alarm is issued, communicated data

is guaranteed. However, if any of these counters indicated in the diagnosis

information above reaches a very large value rapidly, noise is probably

disturbing serial communication. So, provide noise protection sufficiently.

NOTE For details, refer to the relevant manual of FANUC SERVO MO-

TOR αi Series.

358

V ready–off information

DGN

Information for analyzing the cause of the V ready–off alarm (servo alarm

ALM401).

Convert an indicated value to a binary value, then check bits 5 to 14. When

the amplifier is activated, bits 5 to 14 are set to 1 sequentially starting with

bit 5 if the amplifier is started normally. When you check these bits

sequentially from the lower bit to the higher bit, the processing of the bit first

set to 0 has failed, indicating the cause of the V ready–off alarm.

#15

#14 #13 #12 #11 #10 #09 #08

SRDY DRDY INTL CRDY

#07

#06 #05 #04 #03 #02 #01 #00

*ESP

*ESP : Converter emergency stop reset state

CRDY : Converter ready for operation

INTL : DB relay reset completed

DRDY : Amplifier ready for operation (amplifier)

SRDY : Amplifier ready for operation (software)

NOTE For details, refer to the relevant manual of FANUC SERVO MO-

TOR αi Series.
