8.4 Alarms Displayed on Spindle Servo Unit and CNC

562

8.4.2 Errors displayed on the spindle amplifier

NOTE*

Note that the meanings of the SPM indications differ depending on

which LED, the red or yellow LED, is on. When the yellow LED is

on, an error code is indicated with a 2–digit number. Error codes

can be checked with diagnostic information (DGN710, 711, 730,

and 731).

When the red LED is on, the SPM indicates the number of an alarm

generated in the serial spindle.

³ See “Subsec 8.4.1.”

SPM

indica-

tion(*1)

Faulty location and

remedy

Description

00 Check the *ESP and MRDY

sequence. (For MRDY, pay

attention to the parameter

setting regarding the use of

the MRDY signal (PRM4001

#0).)

Although neither *ESP (emergency stop

signal; there are two types of signals in-

cluding the PMC signal and PSM contact

signal (NOTE*

)) nor MRDY (machine

ready signal) is input, SFR (forward rota-

tion signal)/SRF (reverse rotation sig-

nal)/ORCM (orientation command) is in-

put.

01 Check the spindle motor

speed detector parameter

(PRM4011#0, #1, #2).

When the spindle motor has a high–reso-

lution magnetic pulse coder (Cs sensor)

(PRM4001#6, #5 are set to 0 and 1, re-

spectively), 128 /rev is to be set for the

speed detector (PRM4011#2, #1, #0 are

set to 0, 0, and 1, respectively). Howev-

er, a value other than 128 /rev is set. In

this case, the motor is not excited.

02 Check the parameters for the

detector for Cs contour con-

trol (PRM4001#5 and 4018

#4).

Although use of a high–resolution mag-

netic pulse coder (PRM4001#5=1) or

use of the Cs contour control function by

the sensor (PRM4018#4=1) is not set,

a Cs control command is input. In this

case, the motor is not excited.

03 Check the position coder sig-

nal parameter (PRM4001#2).

Although use of the position coder signal

(PRM4001#2=1) is not set, a servo mode

(rigid tapping, spindle positioning) or

spindle synchronization command is in-

put. In this case, the motor is not excited.

04 Check the orientation soft-

ware option.

Although the orientation option is not set,

an orientation command signal (ORCM)

is input.

05 Check the spindle output

switching software option and

power line status signal

(RCH).

Although the output switching option is

not set, the low–speed winding is se-

lected (RCH = 1).

06 Check the sequence (CON,

SFR, SRV).

Although the Cs contour control mode is

specified, PMC signal (SFR/SRV) is not

input.

07 Check the sequence (SFR,

SRV).

Although the servo mode (rigid tapping,

spindle positioning) is specified, PMC

signal (SFR/SRV) is not input.

09 Check the sequence

(SPSYC, SFR, SRV)

Although spindle synchronization mode

is specified, PMC signal (SFR/SRV) is

not input.
