19.1 Inputting/Outputting Data

904

(2) Inputting a file

1 Press the rightmost soft key

(continuous menu key) on the ALL

IO screen.

2 Press soft key [FLOPPY].

3 Select EDIT mode. The floppy screen is displayed.

4 Press soft key [(OPRT)]. The screen and soft keys change as shown

below.

The floppy screen is displayed only in EDIT mode. In all other modes,

the ALL IO screen is displayed.

F SRH

[][][][][]

READ PUNCH DELETE

READ/PUNCH (FLOPPY) O1234 N12345

MDI * * * * * * * * * * * * * 12:34:56

5 Press soft key [READ].

6 Enter the number of a file or program to be input.

⋅ Setting a file number: Enter the number of the desired file, then

press soft key [F SET].

⋅ Setting a program number: Enter the number of the desired

program, then press soft key [O SET].

STOP EXECCANF SET O SET

7 Press soft key [EXEC].

The specified file or program is read, and the “INPUT” indicator blinks

at the lower–right corner of the screen. Upon the completion of input,

the “INPUT” indicator is cleared from the screen.

(3) Outputting a file

1 Press the rightmost soft key

(continuous menu key) on the ALL

IO screen.

2 Press soft key [FLOPPY].

3 Select EDIT mode. The floppy screen is displayed.
