Series 16i/18i/160i/180i - PB Operators manual Page 127

Operators manual
PROGRAMMING
B–63684EN/01
9. PRESSING FUNCTION
101
WARNING
1 The following commands only are executable in nibbling
mode.
(i) X, Y positioning command by G00
Provided that the T code and F1-digit command can
be included in the same block where the X, Y
positioning is made by G00 to the first punch point of
nibbling.
(ii) G26 (bolt hole circle), G76 (line at angle), G77 (arc),
G78, G79 (grid), G86 (share proofs), G87 (square),
G88 (radius), G89 (cut at angle)
The movement amounts along the X-axis and Y-axis
to respective positioning points should not exceed the
parameter set value (Nos. 16188, 16189), except
when the first positioning point is equivalent to the first
punch point of nibbling.
(iii) G01, G02, G03, G41 and G42 commands in the range
described in 9.4.2.
2 The positioning distance commandable by the X-Y
positioning command by G00 is not composite distance
p∆
x
2
+ ∆y
2
obtained by the movement amounts along
X-axis and Y-axis.
If the absolute value of the movement amount along either
X-axis or Y-axis exceeds the parameter set value (Nos.
16188, 16189), alarm (No. 4521) is issued.
This provision also applies to G26, G76, G77, G78, G79,
G86, G87, G88 and G89, correspondingly.
3 When offset was made by the tool diameter by G41 or G42
to G01, G02 and G03 as described in example 5 the offset
straight line or circular arc is divided by the pitch
commanded by address Q.
Be careful since the above division differs form such a case
that a commanded circular arc is divided by a commanded
pitch, like in G68 (circular nibbling).
9.4.3
Notes on Nibbling by M
Function
