OPERATION
B–63684EN/01
8. DATA INPUT/OUTPUT
485
Punch operation can be performed in the same way as in the foreground.
This function alone can punch out a program selected for foreground
operation.
<O> (Program No.)
[PUNCH] [EXEC]: Punches out a specified program.
<O> H–9999I
[PUNCH] [EXEC]: Punches out all programs.
A program is output to paper tape in the following format:
ER
(%)
Program
Feed of 3 feet
Feed of 3 feet
ER
(%)
If three–feet feeding is too long, press the
CAN
key during feed
punching to cancel the subsequent feed punching.
A space code for TV check is automatically punched.
When a program is punched in ISO code, two CR codes are punched after
an LF code.
LF CR CR
Press the
RESET
key to stop punch operation.
All programs are output to paper tape in the following format.
Program Program Program
Feed of 1–feet
Feed of 3–feet
ER
(%)
ER
(%)
The sequence of the programs punched is undefined.
D Punching programs in
the background
Explanations
(Output to an NC tape)
D Format
D TV check
D ISO code
D Stopping the punch
D Punching all programs
