OPERATION11. SETTING AND DISPLAYING DATA
(b)Number of tools for which the turret is indexed (parameter No.
When T-axis control is specified (TCL, bit 4 of parameter No.
16260, is set to 1), specify the total number of tools for which the
turret is indexed. The setting must not be greater than the number
of tools to be used.
When the number of tools to be used is 50 and the number of tools
for which the turret is indexed is 45, the T-axis control applies to
tool Nos. 001 to 045 and does not apply to tool Nos. 046 to 050.
For the tool numbers, see Item 184.108.40.206.
(c) Number of a tool to be initially selected (parameter No. 16267)
When T-axis control is specified, specify the number of the tool to
be selected when reference position return is completed after
power-on. Settings range from 0 to 9999.
The tool must be mounted at the 0-position of the turret. The tool
also needs to be registered on the tool number registration screen
(see Item 220.127.116.11) before the number of the tool is specified.
(d)Number of pulses sent to the turret per rotation (parameter No.
When T-axis control is specified, specify the number of pulses sent
to the turret per rotation.
(e) Number of punch operations (parameter No. 16269)
Specify the number of punch operations for the tool used. Settings
range from 0 to 99999999.
Data items (a) to (e) can also be specified on the parameter
