Series 16i/18i/160i/180i - PB Operators manual Page 674

Operators manual

Page of 792

/ 792

OPERATION11. SETTING AND DISPLAYING DATA

B–63684EN/01

648

When the CNC and machine are connected, parameters must be set to

determine the specifications and functions of the machine in order to fully

utilize the characteristics of the servo motor or other parts.

This chapter describes how to set parameters on the MDI panel.

Parameters can also be set with external input/output devices such as the

Handy File (see Chapter 8).

In addition, pitch error compensation data used for improving the

precision in positioning with the ball screw on the machine can be set or

displayed by the operations under function key

SYSTEM

See Chapter 7 for the diagnostic screens displayed by pressing function

key

SYSTEM

11.5

SCREENS

DISPLAYED BY

FUNCTION KEY <sys>

SYSTEM
