Series 16i/18i/160i/180i - PB Operators manual Page 82

Operators manual
PROGRAMMING5. FEED FUNCTIONS
B–63684EN/01
56
If Rc is much smaller than Rp, Rc/Rp80; the tool stops. A minimum
deceleration ratio (MDR) is to be specified with parameter No. 1710.
When Rc/Rp
xMDR, the feedrate of the tool is (F×MDR).
WARNING
When internal circular cutting must be performed together
with automatic override for inner corners, the feedrate of the
tool is as follows:
(automatic override for the inner corners)
× (feedrate override)
F
Rc
Rp
This function automatically controls the feedrate at a corner according to
the corner angle between the machining blocks or the feedrate difference
between the blocks along each axis.
This function is effective when ACD, bit 6 of parameter No. 1601, is set
to 1, the system is in G64 mode (machining mode), and a cutting–feed
block (block A) is followed by another cutting–feed block (block B).
The feedrate between machining blocks is controlled according to the
corner angle between the blocks or the feedrate difference between the
blocks along each axis. These two methods can be switched with CSD,
bit 4 of parameter No. 1602.
This function decelerates the feedrate when the angle between blocks A
and B on the selected plane is smaller than the angle specified in parameter
No. 1740. The function executes block B when the feedrates along both
the first and second axes are smaller than the feedrate specified in
parameter No. 1741. In this case, the function determines that the number
of accumulated pulses is zero.
5.4.3
Automatic Corner
Deceleration
5.4.3.1
Corner deceleration
according to the corner
angle
