OPERATION
B–63684EN/01
8. DATA INPUT/OUTPUT
505
CNC programs stored in memory can be grouped according to their
names, thus enabling the output of CNC programs in group units.
Procedure for Outputting a Program List for a Specified Group
1 Display the program list screen for a group of programs.
PROGRAM DIRECTORY (GROUP) O0001 N00010
EDIT
**** *** *** ***
16 : 52 : 13
PRGRM DIR (OPRT)
PROGRAM (NUM.) MEMORY (CHAR.)
USED: 60 3321
FREE: 2 429
O0020 (GEAR–1000 MAIN )
O0040 (GEAR–1000 SUB–1)
O0200 (GEAR–1000 SUB–2)
O2000 (GEAR–1000 SUB–3)
>_
2 Press the [(OPRT)] operation soft key.
3 Press the right–most soft key
(continuous menu key).
4 Press the
[PUNCH] operation soft key.
5 Press the
[AL–GRP] operation soft key.
The CNC programs in the group for which a search is made are
output. When these programs are output to a floppy disk, they are
output to a file named GROUP.PROGRAM.
8.10
OUTPUTTING A
PROGRAM LIST FOR
A SPECIFIED GROUP
Procedure
BG–EDT O–SRH GROUP
PUNCH
READ
AL–GRP STOP EXECCAN
