Procedure for displaying and setting the pitch error compensation data
1 Set the following parameters:
S Number of the pitch error compensation point at the reference
position (for each axis): Parameter 3620
S Number of the pitch error compensation point having the smallest
value (for each axis): Parameter 3621
S Number of the pitch error compensation point having the largest
value (for each axis): Parameter 3622
S Pitch error compensation magnification (for each axis): Parameter
3623
S Interval of the pitch error compensation points (for each axis):
Parameter 3624
S Travel distance per revolution of pitch error compensation of the
rotary axis type (for each axis): Parameter 3625
2 Press function key
SYSTEM
.
3 Press the continuous menu key
, then press chapter selection soft
key
[PITCH].
The following screen is displayed:
PIT–ERROR SETTING O0000 N00000
NO.DATA
0000 0
0001 0
0002 0
0003 0
0004 0
0005 0
0006 0
0007 0
0008 0
0009 0
NO.DATA
0010 0
0011 0
0012 0
0013 0
0014 0
0015 0
0016 0
0017 0
0018 0
0019 0
NO.DATA
0020 0
0021 0
0022 0
0023 0
0024 0
0025 0
0026 0
0027 0
0028 0
0029 0
(X)
> _
MEM **** *** *** 16:05:59
[ NO.SRH ][ ON:1 ][ OFF:0 ][+INPUT][–INPUT]
4 Move the cursor to the compensation point number to be set in either
of the following ways:
S Enter the compensation point number and press the [NO.SRH]
soft key.
S Move the cursor to the compensation point number using the page
keys,
PAGE
and
PAGE
, and cursor keys, , , , and
.
5 Enter a value with numeric keys and press the [INPUT] soft key.
