PROGRAMMING15. COMPENSATION FUNCTION
B–63684EN/01
186
15
COMPENSATION FUNCTION
This chapter describes the following compensation functions:
CUTTER COMPENSATION C (G40–G42) Sec.15.1, 15.2. . . . . . . . . . .
TOOL COMPENSATION VALUES, NUMBER OF COMPENSATION
VALUES, AND ENTERING VALUES FROM THE PROGRAM (G10)
Sec.15.3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCALING (G50, G51) Sec.15.4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COORDINATE SYSTEM ROTATION (G84, G85) Sec.15.5. . . . . . . . . .
NORMAL DIRECTION CONTROL
(G40.1, G41.1, G42.1 or G150, G151, G152) Sec.15.6. . . . . . . . . . . . .
