PROGRAMMING

B–63684EN/01

19. AXIS CONTROL FUNCTIONS

327

Normal turret punch press machines cannot perform T–axis movement

and C–axis movement at the same time because of their machine structure

limits. Therefore, if the T command and C command are issued at the

same time, a CNC executes these commands in sequence.

This function allows the machines that are free from the structure limits

to perform T–axis and C–axis simultaneous control for the reduction of

the cycle time.

(Program example)

X100. Y200. T200. C90

(1) X100. Y200. C (R)

(Normal operation sequence)

(2) T100

(1) C90.

(Operation sequence in this specification)

((R): Command for the reference point)

X100. Y200. T200. C90

(Simultaneous movement along all the axes)

(No movement to the C–axis reference point)

FIN signal

19.4

T–AXIS AND C–AXIS

SIMULTANEOUS

CONTROL
