OPERATION

B–63684EN/01

11. SETTING AND DISPLAYING DATA

603

Displays the program input from the MDI and modal data in the MDI

mode.

Procedure for displaying the program screen for MDI operation

1 Press function key

PROG

2 Press chapter selection soft key

[MDI].

The program input from the MDI and modal data are displayed.

MDI **** *** *** 15:11:15

[ ][ ][ SRH ± ][ SRH ° ][ REWIND ]

PROGRAM (MDI) O1000 N00000

O0000 G00 X100. Y100. ;

G72 X200. Y200. ;

G26 I100. J0 K10 T10 ;

G00 G90 G21 G50 G54 G85

G17 G22 G40 G67 G64

H M

T D

F S

See Section 4.2 for MDI operation.

The modal data is displayed when bit 7 (MDL) of parameter 3107 is set

to 1. Up to 16 modal G codes are displayed. On the 9.5″/10.4″ LCD,

however, the contents of the program are displayed on the right half of the

screen and the modal data is displayed on the left half of the screen,

regardless of this parameter.

During automatic operation, the actual speed, SACT, and repeat count are

displayed. The key input prompt (>_) is displayed otherwise.

11.2.5

Program Screen for

MDI Operation

Procedure

Explanations

D MDI operation

D Modal information

D Displaying during

automatic operation
