OPERATION8. DATA INPUT/OUTPUT

B–63684EN/01

490

Pitch error compensation data are loaded into the memory of the CNC

from a floppy or NC tape. The input format is the same as the output

format. See Section

8.6.4. When a pitch error compensation data is

loaded which has the corresponding data number as a pitch error

compensation data already registered in the memory, the loaded data

replaces the existing data.

Pitch error compensation data

1 Make sure the input device is ready for reading.

2 When using a floppy, search for the required file according to the

procedure in Section

8.2.

3 Press the EMERGENCY STOP button on the machine operator’s

panel.

4 Press function key

OFFSET

SETTING

5 Press the soft key

[SETING] for chapter selection.

6 Enter 1 in response to the prompt for “PARAMETER WRITE

(PWE)” in setting data. Alarm P/S100 (indicating that parameters can

be written) appears.

7 Press soft key

SYSTEM

8 Press the rightmost soft key

(next–menu key)and press

chapter selection soft key

[PITCH].

9 Press soft key

[(OPRT)].

10 Press the rightmost soft key

(next–menu key).

11 Press soft keys [READ] and [EXEC].

Parameters are read into memory. Upon completion of input, the

“INPUT” indicator at the lower–right corner of the screen disappears.

12 Press function key

OFFSET

SETTING

13 Press soft key

[SETING] for chapter selection.

14 Enter 0 in response to the prompt for “PARAMETER WRITE

(PWE)” in setting data.

15 Turn the power to the CNC back on.

16 Release the EMERGENCY STOP button on the machine operator’s

panel.

Parameters 3620 to 3624 and pitch error compensation data must be set

correctly to apply pitch error compensation correctly

(See subsection

11.5.2)

8.6.3

Inputting Pitch Error

Compensation Data

Procedure

Explanations

D Pitch error

compensation
