B–63684EN/01

SAFETY PRECAUTIONS

s–5

WARNINGS AND CAUTIONS RELATED TO

PROGRAMMING

This section covers the major safety precautions related to programming. Before attempting to

perform programming, read the supplied this manual carefully such that you are fully familiar with

their contents.

WARNING

1. Coordinate system setting

If a coordinate system is established incorrectly, the machine may behave unexpectedly as a

result of the program issuing an otherwise valid move command.

Such an unexpected operation may damage the tool, the machine itself, the workpiece, or cause

injury to the user.

2. Positioning by nonlinear interpolation

When performing positioning by nonlinear interpolation (positioning by nonlinear movement

between the start and end points), the tool path must be carefully confirmed before performing

programming.

Positioning involves rapid traverse. If the tool collides with the workpiece, it may damage the

tool, the machine itself, the workpiece, or cause injury to the user.

3. Inch/metric conversion

Switching between inch and metric inputs does not convert the measurement units of data such

as the workpiece origin offset, parameter, and current position. Before starting the machine,

therefore, determine which measurement units are being used. Attempting to perform an

operation with invalid data specified may damage the tool, the machine itself, the workpiece, or

cause injury to the user.

4. Stroke check

After switching on the power, perform a manual reference position return as required. Stroke

check is not possible before manual reference position return is performed. Note that when stroke

check is disabled, an alarm is not issued even if a stroke limit is exceeded, possibly damaging

the tool, the machine itself, the workpiece, or causing injury to the user.
