PROGRAMMING

11. TOOL FUNCTION

(T FUNCTION)

B–63684EN/01

116

The next commanded T–code is sent to the machine beforehand in the

order execution of program. When this function is used, the next

preparation of tool change can be performed by the machine side before

T command is executed. In this function, T–code is searched within the

next 30 blocks and it is sent by a T–code signal.

X1200.Y500. T100 ² Current block

X1000.Y400.

X600. Y500.

X500. Y300. T200 ² Output ahead of T–code

WARNING

1 Do not intervene a manual operation.

2 It is possible to re–start after feed hold, but it is not possible

to re–start after the following operation during feed hold.

@ Program number search, Sequence number search

@ Heading a program

@ Editing operation

3 The custom macro statements is executed before storing 30

blocks buffer. Therefore any macro statements may be not

worked correctly.

EX) O0100 ;

N1 G92 X1800. Y1500. ;

N2 G90 G00 X1000. Y1000. T400 ;

N3 G65 P9500 X500. Y500. T500 ;

N4 G72 X100. Y100. ;

N5 G26 I10. J0 K4 T600 ;

N6 G28 M30 ;

O9500 ;

N10 #100 = 1.

N20 IF [#5001 EQ 0. ] GOTO 50 ;

N30 G90 G00 X#24 Y#25 T#20 ;

N40 GOTO 60 ;

N50 T#100 ;

N60 M99 ;

Since the macro program is executed N10, N20, N50 and

N60 in that order, the ahead of T–code is output T400, T1

and T600 in that order.

NOTE

1T–code is outputed before 1 block in MDI mode.

2 When M–code which is not read into the input buffer is

commanded, the search of T–code is stopped until the M

code is executed.

EX) G90 G00 X1000. Y1000. ; ² Current block

M00 ;

G72 X100. Y100. ;

G26 I10. J0 K4 T600 ; ² Not output until

M00 is executed

11.7

OUTPUT AHEAD OF

T–CODE
