PROGRAMMING19. AXIS CONTROL FUNCTIONS

B–63684EN/01

326

For the C-axis commands between the M code for nibbling mode and the

M code for nibling mode cancel, an alarm is indicated if the C-axis

movement amount per block exceeds the value set with the parameter

(No. 16194).

The C-axis command is ignored when signal TNG is on.

This function automatically compensates the position of the C-axis to

orient each tool in the specified direction. This simplifies mechanical

adjustment such as adjusting the reference position when installing tools.

Up to 20 compensation settings are specified in parameters No. 16430 to

No. 16449. Up to 20 tool numbers are specified in parameters No. 16370

to No. 16389.

The C-axis is compensated when the tool moves around the C-axis after

T commands have been specified.

WARNING

Tool numbers of tools must be specified with address T

followed by up to four digits.

This function compensates backlash along the C-axis for each tool group.

Changing the backlash compensation for each tool group enables

higher-precision machining. Up to 20 compensation settings are

specified in parameters No. 16390 to No. 16409. Up to 20 tool numbers

are specified in parameters No. 16370 to No. 16389.

WARNING

The tool numbers must be specified with address T followed

by up to four digits.

19.3.11

C–axis Command in

Nibbling Mode

19.3.12

T–axis Command

Ignore Signal TNG and

C–axis Command

19.3.13

Compensating the

Position of the C–axis

19.3.14

Compensating

Backlash Along the

C–axis for Each Tool

Group
