PROGRAMMING16. CUSTOM MACRO

B–63684EN/01

292

Meaning

Note

(In case not to

command M code

preventing buffer-

ing or G53 block.)

Number of

Variable

Read

Write

Time information

Read

Write

#3001,#3002 The data is read / writ-

ten at buffering a mac-

ro program.

Read #3011,#3012 The data is read at

buffering a macro pro-

gram.

Automatic operation

control

Write #3003, #3004 Setting data is avail-

able at maximum 2

blocks before a macro

program.

Settings Write #3005 The data is written at

buffering a macro pro-

gram.

Mirror image Read #3007 The data is read at

buffering a macro pro-

gram.

Currently selected

additional workpiece

coordinate system

Read #4130(P)

#4014

(G54 – G59)

The data is read at

maximum 3 blocks

before a macro pro-

gram.

Current position

(Machine coordinate

system)

Read #5021 – #5028 The uncertain position

in moving is read.

Current position

(Workpiece coordi-

nate system)

Read #5041 – #5048 The uncertain position

in moving is read.

Deviated servo

position

Read #5101 – #5108 The uncertain devi-

ation in moving is

read.

Workpiece zero

point offset value

Write #5201 – #5328 The data is written at

buffering a macro pro-

gram.

Example)

O0001 O2000

N1 X10.Y10.; (Mxx ;) Specify preventing buffering M code or G53

N2 M98P2000; N100 #1=#5041;(Reading X axis current position)

N3 Y200.0; N101 #2=#5042;(Reading Y axis current position)

: :

M99;

In above case, the buffering of N2 block is done and the macro program

of O2000 is read and executed during N1 block of main program O1000

execution. Therefore, the current position readings are executed during

axes movements at N1 block. So the unexpected position data can be read

to #1 and #2 because of axes movements. In this case, please specify M

code preventing buffering Mxx ; (or G53 ;) just before N100 block of

O2000. By this, the position data at completing the execution of N1 block

can be read to #1 and #2 because O2000 is executed after completing the

execution of N1 block of O0001.
