OPERATION11. SETTING AND DISPLAYING DATA

B–63684EN/01

612

This section describes the screens displayed by pressing function key

PROG

in the EDIT mode. Function key

PROG

in the EDIT mode can

display the program editing screen and the library screen (displays

memory used and a list of programs). Pressing function key

PROG

in the

EDIT mode can also display the conversational graphics programming

screen and the floppy file directory screen. See Chapter 9 for the program

editing screen and conversational graphics programming screen. See

Chapter 8 for the floppy file directory screen.

Displays the number of registered programs, memory used, and a list of

registered programs.

Procedure for displaying memory used and a list of programs

1 Select the EDIT mode.

2 Press function key

PROG

3 Press chapter selection soft key

[LIB].

SYSTEM EDITION B001 – 02

PROGRAM NO. USED : 11 FREE : 52

MEMORY AREA USED : 1200 FREE : 4320

PROGRAM LIBRARY LIST

O0010 O0001 O0003 O0002 O0555 O0999

O0062 O0004 O0005 O1111 O0969 O6666

O0021 O1234 O0588 O0020 O0040

> _ S 0 T0000

MDI **** *** *** 16:05:59

[ PRGRM ][ LIB ][ ][ C.A.P. ][ (OPRT) ]

PROGRAM O2000 N00130

11.3

SCREENS

DISPLAYED BY

FUNCTION KEY <pr>

(IN THE EDIT MODE)

PROG

11.3.1

Displaying Memory

Used and a List of

Programs

Procedure
