Series 16i/18i/160i/180i - PB Operators manual Page 529

Operators manual
OPERATION
B–63684EN/01
8. DATA INPUT/OUTPUT
503
All tool data are output in the defined format from the memory of the CNC
to a floppy or NC tape.
Outputting Tool Data
1 Make sure the output device is ready for output.
2 Specify the punch code system (ISO or EIA) using a parameter.
3 Press the EDIT switch on the machine operator’s panel.
4 Press function key
OFFSET
SETTING
.
5 Press the rightmost soft key
(next–menu key) two times, then
press soft key [TOOL].
6 Press the rightmost soft key
(next–menu key), then press soft
key [T.NUM.].
7 Press soft key [(OPRT)].
8 Press the rightmost soft key
(next–menu key).
9 Press soft keys [PUNCH] [EXEC].
All tool data are output in the defined format.
Output format is as follows.
%
;
N001T M X Y S P C I J K B ;
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12)
N002T M X Y S P C I J K B
;
;. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
;. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
N136T M X Y S P C I J K B
;
N201T A Y C I J K ;
(1) (2) (13) (5) (8) (9) (10) (11)
N202T A Y C I J K ;
;. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
;. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
N264T A Y C I J K
;
%
8.9.2
Outputting Tool Data
Procedure
Explanations
D Output format
