12. GRAPHICS FUNCTION
B–63684EN/01
OPERATION
668
1) Drawing screen
Press [GRAPH] key after pressing
GRAPH
key, the following graphic
display screen appears.
GRAPHIC O1234 N00200
X 0.000
Y 0.000
123.076
MEM **** *** *** 16:24:05
[ START ][ STOP ][ SBK ][ SEQ. ][ ERASE ]
Y
X
Be selecting this screen, tool paths and holes figures are drawable for
checking NC programs.
2) Software keys, status display for drawing, and ruler
1 MDI address keys are used for drawing.
[START] key : Drawing start key
[STOP] key : Drawing stop key
[ERASE] key : Graphic display erasing key
[SEQ] key : Continuous drawing mode key
[SBK] key : Single block drawing mode key
2 Ruler
The ruler is displayed at the lower right part of the screen. The
value below
shows the length to the line (Input unit).
3) Drawing operation
1 Select either MEMORY mode.
(This is the preparation for automatic operation, such as heading of
a program, etc.)
2 Depress [ERASE] key. ....
Depress this key when the previous graphic display is not required.
After erasing graphic display, the work sheet figure and work
holder mark are drawn as shown in the left figure.
12.4
GRAPHIC DISPLAY
SCREEN AND
DRAWING
