PROGRAMMING

B–63684EN/01

14. FUNCTIONS TO SIMPLIFY

PROGRAMMING

169

With macro numbers 90 to 99, several macros can be stored and called as

a single macro, though the item 14.4.1 “Storage of macros” describes that

another macro cannot be stored while a certain macro is being stored.

Macro numbers 90 to 99, however, only define several macros as a single

macro, but they cannot store any executable commands by themselves.

So, no memory prepared for macros is used. Macro numbers 90 to 99 are

prepared mainly for simplifying programs in the multi-piece machining

function.

U90 ;

U01 ;

. . .

V01 ;

U10 ;

. . .

V10 ;

U15 ;

. . .

V15 ;

G90X10000Y20000T15 ; ² This block is not stored at all.

U02 ; (such a use is no good)

. . .

V02 ;

V90 ;

. . .

W90 ; ² This command is equivalent to the following set of several

commands.

W01 ;

W10 ;

W15 ;

W02 ;

=W90

The number of macros storable by each of macro numbers 90 to 99 is up

to 15.

14.4.5

Storage and Call of

Multiple Macros (Macro

Numbers 90 to 99)

Examples
