PROGRAMMING

B–63684EN/01

14. FUNCTIONS TO SIMPLIFY

PROGRAMMING

183

These commands specify the punch operation from the current position

or the position specified by the G72 command to an end point at

coordinates (x, y) with an interval of q using a tool of diameter d along

an arc of radius r.

G46

X x Y y R r P d Q q ;

G47

G46 :Clockwise punch movement along an arc (CW)

G47 :Counterclockwise punch movement along an arc (CCW)

x : X coordinate of the end point

y : Y coordinate of the end point

r : Radius of the arc

r = 0: Alarm 169 is issued.

r < 0: An arc with a center angle of 180 degrees or more

r > 0: An arc with a center angle of less than 180 degrees

d : Direction in which a tool is shifted relative to the direction in

which the punch moves (can be omitted)

d = 0: The punch moves along the specified arc

d < 0: The punch moves along the inside of the arc

d > 0: The punch moves along the outside of the arc

q : Interval

NOTE

Enter data in the specified units.

14.7.2

Circular Punch

Commands (G46 and

G47)
