APPENDIXC. RANGE OF COMMAND VALUE

B–63684EN/01

708

RANGE OF COMMAND VALUE

Increment system

IS–A IS–B

Least input increment 0.01 mm 0.001 mm

Least command increment 0.01 mm 0.001 mm

Max. programmable dimension ±999999.99 mm ±99999.999 mm

Max. rapid traverse Note 240000 mm/min 240000 mm/min

Feedrate range Note 1 to 240000 mm/min 1 to 240000 mm/min

Incremental feed 0.01, 0.1, 1, 10 mm/step 0.001, 0.01, 0.1, 1 mm/step

Tool compensation 0 to ±999.99 mm 0 to ±999.999 mm

Dwell time 0 to 99999.999 sec 0 to 99999.999 sec

Increment system

IS–A IS–B

Least input increment 0.001 inch 0.0001 inch

Least command increment 0.01 mm 0.001 mm

Max. programmable dimension ±99999.999 inch ±9999.9999 inch

Max. rapid traverse Note 240000 mm/min 240000 mm/min

Feedrate range Note 0.01 to 9600 inch/min 0.01 to 9600 inch/min

Incremental feed 0.001, 0.01, 0.1, 1 inch/step 0.0001, 0.001, 0.01, 0.1 inch/step

Tool compensation 0 to ±99.999 inch 0 to ±99.9999 inch

Dwell time 0 to 99999.999 sec 0 to 99999.999 sec

Linear axis

D In case of millimeter

input, feed screw is

millimeter

D In case of inch input,

feed screw is millimeter
