PROGRAMMING19. AXIS CONTROL FUNCTIONS

B–63684EN/01

324

In 19.3.8, the blocks which C-axis command can be performed were

listed. However, unless the die (tool) which allows C-axis control has

been selected, C-axis commands cannot be made. Therefore, if the die

which does not allow C-axis control is selected, it is necessary to select

a die which allows C-axis control before the C-axis command block or to

select a die which allows C-axis control to the same block as the C-axis

command with the T-command. In the following description of

functions, the die (tool) which allows C-axis control is assumed to be T15

Namely, it is assumed that the axis transfer of the C-axis is possible only

when die T15 has been selected. In the case of a machine which allows

axis transfer of the T-axis only when the C-axis is located at the reference

point (fixed location on the machine which can be reached by manual

reference point return of C-axis).

(a) When there was T command

After the C-axis was positioned to the reference point, execution for

the T-command is started.

Namely, after the C CR

; (CR: setting value of parameter No. 1250,

1251) has been executed, the program command of the block where

there was T-command is executed.

(b)G28 command (automatic reference point return)

After the C-axis has been positioned to the reference point, the X- and

Y-axis reference point return is executed by the G28 command. The

following shows the program examples of the C-axis command and

its operation details:

(1)Sample program 1

N200 X_ Y_ T21;

N210 X_ Y_ C_ ;

In N210 block, C-axis control cannot be conducted since T15 is not

selected.

(2)Sample program 2

N200 X_ Y_ T01;

N210 X_ Y_ T15C_ ;

In N210 block, C-axis motion starts when positioning of the X, Y

and T axes is over and T-command completion signal FIN is

returned. Press start signal PF is sent out when positioning of the

C axis is over.

When the N210 block is programmed as follows:

N210T15C – 1;

C axis starts to move when T-axis positioning is over and

T-command completion signal FIN is returned. Press start signal

PF is not sent out after positioning is finished.

Namely,

(1) signal PF is sent out when there is the X or Y command, and

(2) signal PF is not sent out when there are no X and Y commands.

19.3.9

C–axis Command and

its Operation
