OPERATION11. SETTING AND DISPLAYING DATA

B–63684EN/01

634

This function makes the area used for registering tool numbers, tool

position compensation, punch count, and other tool data available to the

user. This enables the user to customize the registered tool data. This

allows the conventional tool data setting method to be changed and the

number of tools that can be registered to be increased considerably.

The number of usable tools are depended on machine tool builder.

Refer to the manual of the machine tool builder.

A memory area consisting of 16KB (16 1024 bytes) is provided for the

tool data setting function.

Tool data can be customized, as listed below, by specifying parameters.

Individual tools cannot have more than one setting. All registered tools

will have the same setting.

Size (byte)

Data

0 2 4 Description

Tool number × f f 2 bytes: T command having up to 4 digits

4 bytes: T command having up to 8 digits

Tool position compensation X, Y f f f 2 bytes: –32768 to +32767

4 bytes: 0 to "99999999

T–axis machine position f × f 4 bytes: 0 to 99999999

Punch count f f f 2 bytes: 0 to 65535

4 bytes: 0 to 99999999

Tool number for tool change f × × When used,

2 bytes: T command having up to 4 digits

4 bytes: T command having up to 8 digits

Tool figure for graphics(*1) f × × Always 13 bytes

Tool life management(*2) f × × When used,

2 bytes: 0 to 65535

4 bytes: 0 to 99999999

Multitool subtool number(*3) f f × 2 bytes: Up to 4 digits

Magazine number plus subtool number can be registered.

Multitool angle(*3) f × f 4 bytes: 0 to 360000 deg

Multitool tool position compensation

X, Y(*3)

f f f 2 bytes: –32768 to +32767

4 bytes: 0 to "99999999

Tool figure for multitool graphics(*3) f × × Always 13 bytes

*1 The graphic function is necessary. f : Can be selected by setting a parameter

*2 The tool life management function is necessary. × : Cannot be selected by setting a parameter

*3 The multitool control function is necessary.

11.4.3.8

Tool data setting

function

General

Registration area

Type and size of tool

data
