Series 16i/18i/160i/180i - PB Operators manual Page 657

Operators manual
OPERATION
B–63684EN/01
11. SETTING AND DISPLAYING DATA
631
The upper digit of the tool figure (C) specifies the color of a line drawing
and the lower digit specifies the figure.
Upper digit Lower digit
0 : Green 0 : Asterisk
1 : Red 1 : Circle (line drawing)
2 : Green 2 : Quadrangle (line drawing)
3 : Yellow 3 : ellipse (line drawing)
4 : Blue 4 : Circle (filled–in drawing)
5 : Pink 5 : Quadrangle (filled–in drawing)
6 : Sky blue 6 : ellipse (filled–in drawing)
7 : White
8 : Gray
When the optional function for controlling multiple tools is used, sub-tool
numbers, the angles used for indexing the turret for sub-tools, and
position compensation along the Y-axis can be displayed and specified.
(1)Displaying the screen
1 Press the
OFFSET
SETTING
function key.
2 Press the
menu key several times until the [M.TOOL] soft
key appears.
3 Press the [M.TOOL] soft key to display the tool number
registration screen for multiple tools.
MULTI TOOL O0010 N00000
NO. M.TOOL ANGLE Y–OFFSET
001 10 0 2000
002 11 135000 2000
003 12 200000 2000
004 20 0 19000
005 21 45000 19000
006 22 90000 19000
007 23 180000 19000
008 24 270000 19000
009 30 0 7000
010 31 120000 7000
>_
MDI **** *** *** 13:52:46
[ SHAPE ][ M.TOOL ][ ][ ][(OPRT)]
Fig. 11.4.3.6 Tool Number Registration Screen for Multiple Tools
The first line indicates the title and the second line contains the tool data.
The leftmost number is a sub-tool registration number for multiple tools.
(2)Setting items from the MDI
1 Set the mode to MDI.
2 Press the
OFFSET
SETTING
function key. Then press the [SETING] soft key
to enable the parameter write operation. The CNC indicates alarm
No. 100.
3 Display the tool number registration screen for multiple tools by
following the steps described in (1).
11.4.3.6
Displaying and setting
items on the tool number
registration screen for
multiple tools
