OPERATION
B–63684EN/01
11. SETTING AND DISPLAYING DATA
625
The numbers of the tools to be used, tool position compensation, and
turret positions (mechanical positions around the T-axis) indexed for tools
can be displayed and specified.
(1)Displaying the screen
1 Press the
OFFSET
SETTING
function key.
2 Press the
menu key several times until the [TOOL] soft key
appears.
3 Press the [TOOL] soft key to display the initial tool registration
screen (Fig. 11.4.3.1).
4 Press the
menu key. Then press the [T.NO] soft key to display
the tool number registration screen.
TOOL SET (NUMBER) O0010 N00000
NO. TOOL POSITION X–OFFSET Y–OFFSET
001 0001 0 0 0
002 0002 5000 0 0
003 0003 10000 0 0
004 0004 15000 0 0
005 0005 20000 0 50000
006 0006 25000 0 0
007 0007 30000 0 0
008 0008 35000 0 0
009 0009 40000 0 50000
010 0010 45000 0 0
>_
MDI **** *** *** 13:38:58
[ T.NUM. ][ T.CHG.][ T.CNT.][ SHAPE ][(OPRT)]
Fig. 11.4.3.2 Tool number registration screen
The first line indicates the title and the second line contains the tool data.
The leftmost number is a tool registration number.
(2)Setting items from the MDI
1 Set the mode to MDI.
2 Press the
OFFSET
SETTING
function key. Then press the [SETING] soft key
to enable the parameter write operation. The CNC indicates alarm
No. 100.
3 Display the tool number registration screen by following the steps
described in (1).
4 Move the cursor to the item to be changed.
Method 1
Move the cursor to the item to be changed with the page keys and
cursor keys.
Method 2
Change the mode of the soft keys to the operation selection mode
using the [(OPRT)] soft key. Enter the registration number of the
tool for which data is to be changed, then press the [NO.SRH] soft
key. Move the cursor to the item to be changed with the cursor
keys.
11.4.3.2
Displaying and setting
items on the tool number
registration screen
