PROGRAMMING

B–63664EN/02

10. PROGRAM CONFIGURATION

121

Major addresses and the ranges of values specified for the addresses are

shown below. Note that these figures represent limits on the CNC side,

which are totally different from limits on the machine tool side. For

example, the CNC allows a tool to traverse up to about 100 m (in

millimeter input) along the X axis.

However, an actual stroke along the X axis may be limited to 2 m for a

specific machine tool.

Similarly, the CNC may be able to control a cutting federate of up to 240

m/min, but the machine tool may not allow more than 3 m/min. When

developing a program, the user should carefully read the manuals of the

machine tool as well as this manual to be familiar with the restrictions on

programming.

Table 10.2 (c) Major addresses and ranges of command values

Function

Address Input in mm Input in inch

Program number O

(1)

1–9999 1–9999

Sequence number N 1–99999 1–99999

Preparatory function G 0–99 0–99

Dimension word X, Y, Z,

U, V, W,

A, B, C,

I, J, K, R,

99999.999mm 9999.9999inch

Feed per minute F 1–240000mm/min 0.01–9600.00

inch/min

Laser function

S 0 to 7000 W 0 to 7000 W

P 5 to 2000 Hz 5 to 2000 Hz

Q 0 to 100 % 0 to 100 %

R 0 to 99999.999 se-

conds

0 to 99999.999 se-

conds

E 1 to 30, 101 to 110 1 to 30, 101 to 110

Auxiliary function

M 0–99999999 0–99999999

B 0–99999999 0–99999999

Offset number H, D 0–400 0–400

Dwell X, P 0–99999.999s 0–99999.999s

Designation of a pro-

gram number

P 1–9999 1–9999

Number of repetitions P 1–9999 1–9999

NOTE

In ISO code, the colon ( : ) can also be used as the address

of a program number.

D Major addresses and

ranges of command

values
