16. HIGH SPEED CUTTING FUNCTIONS

319

In the following tables, AI control means the AI contour control/AI nano

contour control mode.

(1)Parameters related to linear acceleration/deceleration before

interpolation

Parameter

Parameter number

Parameter

Normal

Ad-

vanced

preview

control

contour

Acceleration/deceleration type (A or B) FWB/1602#0 None

Parameter 1 for setting the acceleration 1630 1770

Parameter 2 for setting the acceleration 1631 1771

Feedrate at which an overtravel alarm occurs 1784

(2)Parameters related to automatic corner deceleration

Parameter

Parameter number

Parameter

Normal

Ad-

vanced

preview

control

contour

Method for determining whether to perform

automatic corner deceleration (angle/fee-

drate difference)

CSD/1602#4 None

Lower feedrate limit (control according to the

angle)

1778 1777 None

Angle at which automatic corner deceleration

is performed (control according to the angle)

1740 1779 None

Allowable feedrate difference for all axes

(control according to the feedrate difference)

1780 None

Allowable feedrate difference for each axis

(control according to the feedrate difference)

1783

Acceleration/deceleration type

(Type A/Type B)

FWB/1602#0 None

(3) Parameter related to feedrate clamping by acceleration

Parameter

Parameter number

Parameter

Normal

Ad-

vanced

preview

control

contour

Parameter for determining the allowable ac-

celeration

None 1785

D Corresponding

parameter numbers in

the normal mode,

advanced preview

control mode, and AI

contour control/AI nano

contour control mode
