APPENDIX

C. RANGE OF COMMAND VALUE

B–63664EN/02

832

RANGE OF COMMAND VALUE

Increment system

IS–B

Least input increment 0.001 mm

Least command increment 0.001 mm

Max. programmable dimension ±99999.999 mm

Max. rapid traverse Note 240000 mm/min

Feedrate range Note 1 to 240000 mm/min

Incremental feed 0.001, 0.01, 0.1, 1 mm/step

Cutter compensation 0 to ±999.999 mm

Dwell time 0 to 99999.999 sec

Increment system

IS–B

Least input increment 0.0001 inch

Least command increment 0.001 mm

Max. programmable dimension ±9999.9999 inch

Max. rapid traverse Note 240000 mm/min

Feedrate range Note 0.01 to 9600 inch/min

Incremental feed 0.0001, 0.001, 0.01, 0.1 inch/step

Cutter compensation 0 to ±99.9999 inch

Dwell time 0 to 99999.999 sec

Linear axis

D In case of millimeter

input, feed screw is

millimeter

D In case of inch input,

feed screw is millimeter
