PROGRAMMING 18. SPECIFYING THE LASER FUNCTION
B–63664EN/02
369
#7
15007
#6 #5 #4
XSC
#3
ECK
#2
ESE
#1 #0
[Data type] Bit
ESE If piercing is to be executed in edge machining, it is:
0 : Executed upon the completion of distribution.
1 : Executed after a smoothing error check is performed upon the
completion of distribution.
ECK In edge machining, the angle is judged with:
0 : The actual machining path.
1 : The path in the machining program.
CAUTION
This setting is ignored if bit 4 of parameter No. 15012 is set
to 1.
XSC In exact stop mode, the edge machining function is:
0 : Not executed.
1 : Executed.
#7
OVE15010
#6 #5 #4 #3 #2 #1 #0
[Data type] Bit
OVE Edge machining and feedrate clamp by arc radius:
0 : Cannot be used at the same time.
1 : Can be used at the same time.
CAUTION
Set this parameter to 1.
#7
15011
#6 #5
CSC
#4 #3
LVE
#2 #1 #0
EDS
[Data type] Bit
EDS For machining for the return distance in edge machining and startup
machining, the cutting conditions are assumed as follows:
0 : The cutting conditions are set as conventional.
1 : As the laser power, assist gas type, and assist gas pressure, the
conditions for piercing in edge machining are used.
CAUTION
This setting takes priority over bit 3 of parameter No. 1511.
LVE Assist gas switching at the start of edge machining and the start of the
subsequent return distance cutting is performed as follows:
0 : The conventional specifications are observed.
1 : The settling time is ignored if the gas type and gas pressure remain
unchanged.
