PROGRAMMING

B–63664EN/02

16. HIGH SPEED CUTTING FUNCTIONS

325

Auxiliary functions/spindle–speed functions

f : Can be specified. : Cannot be specified.

Name Function

Auxiliary function (Mxxxx) f The function code and function strobe signals

are output only.

Second auxiliary function (Bxxxx) f The function code and function strobe signals

are output only.

High–speed M/S/T/B interface f

Multiple miscellaneous function

specification

M code group check f

Laser function

Ę The command can be issued.

The command cannot be issued.

Name Function

Laser output command Ę G01S_P_Q_; Can be issued.

Piercing command (G24) Ę High–speed piercing is included.

Assist gas command (G32) Ę

Z–axis gap control (G13/G14) Ę Performing Z–axis gap control pre-

vents the Z–axis from being subjected

to AI contour control.

Power control (G63) Ę

Machining condition setting func-

tion

Ę The E code command can be issued.

However, neither a cutter compensa-

tion amount nor a feedrate can be

specified.

Edge cutting and start–up cutting Ę

Step control

Beam delay control Ę A delay amount is specified in a sepa-

rate parameter.

Cutting restart function

Constant–optical path length

control

Ę A mirror axis under constant–optical

path length control cannot be sub-

mitted to AI contour control.

Extended buffer Ę

Interaction control Ę

Attitude control A and B Ę Cannot be used simultaneously with

helical interpolation B.

Three–dimensional transform

function (G98/G99)

Three–dimensional coordinate

transform function (G68/G69)

Spatial corner rounding insertion

(G33/G34)

Spatial arc interpolation (G12)

Near–point search

Machining head A–axis length

compensation function (G71)

Program restart (laser specifica-

tion)
