16i/160i-LB Operators manual Page 371

Operators manual

Page of 912

/ 912

PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

347

EGM15096

SDB

FOV

SQ0

#3 #2

PCD

PCF

PCP

PCP Specifies whether to control the power specification value with the

feedrate.

0 : Does not control the value.

1 : Controls the value.

PCF Specifies whether to control the pulse frequency with the feedrate.

0 : Does not control the frequency.

1 : Controls the frequency.

PCD Specifies whether to control the pulse duty with the feedrate.

0 : Does not control the pulse duty.

1 : Controls the pulse duty.

SQ0 If 0 is set as either the specified peak power (S) or specified pulse duty

cycle (Q), the power control function is:

0 : Performed.

1 : Stopped.

Whether the specified peak power or pulse duty cycle has become 0 or not

is determined by the peak power setting in parameter No. 15040 and the

pulse duty cycle setting in parameter No. 15042.

Therefore, even when these parameters are set to 0 by a method other than

the specification of addresses S, P, and Q in a machining program, power

control is stopped.

FOV When the feedrate override has been changed in the power control mode,

the feedrate used as the reference feedrate for power control is:

0 : Not changed.

1 : The feedrate overridden by the new override value.

SDB To set the allowable variation width of power control feedrate (parameter

No. 15095):

0 : Specify a feedrate (mm/min) directly.

1 : Set the percentage (0 to 100%) to the specified feedrate used when the

system enters the power control mode.

EGM In edge machining mode and start–up machining mode:

0 : Power control mode is canceled.

1 : Power control is stopped only during the return distance movement in

edge machining and start–up machining.

Edge machining mode and start–up machining mode refer to the states in

which E numbers specifying the respective cutting conditions for edge

machining and start–up machining have been selected.

15097 Parameter for calculating the rate of output change (output at a feedrate (F) of 0)

[Data unit] W

[Data range] 0 to 7000

Sets the power specification value corresponding to Mo, i.e., the value

assumed when the feedrate (F) is equal to 0. The rate of output change is

calculated with this value and the output value specified when power

control mode is ON (Mc).
