A file (NC program) on the host computer can be read to the CNC
memory.
For the host file list screen
1 Place the CNC in the EDIT mode.
2 Display the host file list screen.
3 Press the [READ] soft key.
4 Type the file number or file name of an NC program to be input, with
the MDI keys.
[Input format]
<file–number>
or
<file–name>
5 Press the [EXEC] soft key.
6 During input, “INPUT” blinks in the lower–right corner of the screen.
CAUTION
1 If the CNC memory holds an NC program that has the same
O number as that of an NC program to be input, the NC
program in the CNC memory is overwritten when bit 2 of
parameter No. 3201 is set to 1.
2 If an NC program is input when bit 0 of parameter No. 3201
is set to 1, all NC programs in the CNC memory are
automatically deleted before NC program input.
[Example of use]
When a file with the file name O0001.DAT held on the hard disk
embedded to the host computer is to be input to the CNC memory, enter
O001.DAT. Note, however, that the O number input to the CNC memory
depends on the O number described in the file named O0001.DAT.
NOTE
When a file is input from this screen to the CNC memory, the
O number described in the file is input.
8.12.1.4
NC program input
Procedure
