PROGRAMMING18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

348

15098

Parameter for calculating the rate of frequency change (frequency at a feedrate

(F) of 0)

[Data unit] Hz

[Data range] 5 to 2000

Sets the frequency corresponding to Mo, i.e., the frequency assumed

when the feedrate (F) is equal to 0. The rate of output change is calculated

with this value and the frequency specified when power control mode is

ON (Mc).

15099 Parameter for calculating the rate of duty change (output at a feedrate (F) of 0)

[Data unit] %

[Data range] 0 to 100

Sets the duty corresponding to Mo, i.e., the duty assumed when the

feedrate (F) is equal to 0. The rate of duty change is calculated with this

value and the duty specified when power control mode is ON (Mc).

If the laser power control function is to be used in high–precision contour

control mode (HPCC mode), enable laser power control mode before

setting high–precision contour control mode. Similarly, cancel

high–precision contour control mode before canceling laser power

control mode.

The laser power control function cannot be used together with the pulse

enhanced function. The pulse enhanced function is not effective in power

control mode.

The laser power control function can be used on a linear axis only. It

cannot, therefore, be used together with any function that causes rotation

about a rotation axis, such as the cylindrical interpolation function.

The laser power control function cannot be used with the

three–dimensional machining functions.

Limitations

D High–precision contour

control mode

D Pulse enhanced function

D Use on a rotation axis

D Three–dimensional

machining functions
