APPENDIXG. ALARM LIST

B–63664EN/02

848

Number ContentsMessage

222 DNC OP. NOT ALLOWED IN BG.–

EDIT

Input and output are executed at a time in the background edition.

Execute a correct operation.

224 RETURN TO REFERENCE POINT Reference position return has not been performed before the automatic

operation starts. Perform reference position return only when parameter

ZRN

(No.1005#0) is 0.

231 ILLEGAL FORMAT IN G10 OR L50 Any of the following errors occurred in the specified format at the

programmable–parameter input.

1) Address N or R was not entered.

2) A number not specified for a parameter was entered.

3) The axis number was too large.

4) An axis number was not specified in the axis–type parameter.

5) An axis number was specified in the parameter which is not an axis

type.

6) An attempt was made to reset bit 4 of parameter 3202 (NE9) or

change parameter 3210 (PSSWD) when they are protected by a

password. Correct the program.

232 TOO MANY HELICAL AXIS COM-

MANDS

Three or more axes (in the normal direction control mode two or more

axes) were specified as helical axes in the helical interpolation mode.

233 DEVICE BUSY When an attempt was made to use a unit such as that connected via the

RS–232–C interface, other users were using it.

239 BP/S ALARM While punching was being performed with the function for controlling ex-

ternal I/O units ,background editing was performed.

240 BP/S ALARM Background editing was performed during MDI operation.

4000 P/S ALARM Although the end of a record is reached, the near point is not found

during near point search. ”END OF RECORD” was read during pro-

gram restart (laser specification).

4001 P/S ALARM The Z–axis is specified as the gap control axis during near point

search or program restart (laser specification).

4002 G CODE UNAVAILABLE DURING

G53 is specified in independent axis mode (bit 3 of PRM. 15600, MIA

= 1) during near point search or program restart (laser specification).

4004 THREE–DIMENSIONAL COORDI-

NATE CONVERSION ALARM

One or two of the I, J, and K commands are not specified or a com-

mand for the X, Y, Z, 4, or 5 axis is not specified.

4005 THREE–DIMENSIONAL COORDI-

NATE CONVERSION ALARM

G27, G28, or G29 was issued during three–dimensional coordinate

conversion.

4006 THREE–DIMENSIONAL COORDI-

NATE CONVERSION ALARM

G68 was issued again during three–dimensional coordinate conver-

sion.

4007 THREE–DIMENSIONAL COORDI-

NATE CONVERSION ALARM

G12 (spatial circular interpolation) was issued during three–dimen-

sional coordinate conversion.

4008 THREE–DIMENSIONAL COORDI-

NATE CONVERSION ALARM

Scaling or coordinate rotation was specified during three–dimension-

al coordinate conversion.

4010 THREE–DIMENSIONAL TRANS-

FORM FORMAT ERROR

The G98 command format is invalid.

4011 MATRIX TRANSFORM ERROR No matrix can be created during G98 processing.

4012 COORDINATE CONVERSION ER-

ROR

Coordinate conversion cannot be performed for G98.

4016 P/S ALARM The value of arc radius R specified in G33 mode is too large.

4017 P/S ALARM A G code in group 01 other than G01 was issued in G33 mode. Cut-

ter compensation was specified in G33 mode.

4021 P/S ALARM A negative value is specified as the length of the nozzle. The nozzle

length falls outside the specification range. The total of the second

arm length and nozzle length must be a maximum of 500 mm

(19.685 inches).

4025 P/S ALARM The spatial arc or spatial corner rounding command specifies axis

movement for an axis other than the first to fifth axes.
