PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

361

By specifying an E code together with G24, the conditions required for

machining can be set.

S When an E code is combined with the G code

G24 E__;

S When an E code is specified alone

E__;

G24;

S E_: Piercing data set number (101 to 103, 101 to 110)

When G24 is specified, the CNC calls the set of data corresponding to the

E code, and piercing is performed according to the data. An E code can

also be specified alone.

Once an E code has been specified, G24 not followed by an additional E

code performs processing under the same machining conditions.

By specifying an E code together with a cutting feed command, the

conditions required for machining can be set.

S When an E code is combined with a G code

G01 (G02, G03, G12) E__;

S When an E code is specified alone

E__;

G01 X__Y__;

S E_: Machining data set number (1 to 10, 1 to 30)

When a machining feed command is executed, the CNC calls the set of

data corresponding to the E code, and machining is performed according

to the data. An E code can also be specified alone.

Once an E code has been specified, a machining feed command not

followed by an additional E code performs processing under the same

machining conditions.

18.7.1

Piercing Command

Format

Explanations

18.7.2

Cutting Command

Format

Explanations
