PROGRAMMING

B–63664EN/02

13. CUSTOM MACRO

251

Specify a conditional expression after IF.

If the specified conditional expression is satisfied, a branch to sequence

number n occurs. If the specified condition is not satisfied, the next block

is executed.

IF [#1 GT 10] GOTO 2 ;

N2 G00 G91 X10.0 ;

If the value of variable #1 is greater than 10, a branch to sequence number

N2 occurs.

If the condi-

tion is not sa-

tisfied

Processing If the condition is satisfied

If the specified conditional expression is satisfied, a predetermined macro

statement is executed. Only a single macro statement is executed.

IF [#1 EQ #2] THEN#3=0 ;

If the values of #1 and #2 are the same, 0 is assigned to #3.

A conditional expression must include an operator inserted between two

variables or between a variable and constant, and must be enclosed in

brackets ([, ]). An expression can be used instead of a variable.

Operators each consist of two letters and are used to compare two values

to determine whether they are equal or one value is smaller or greater than

the other value. Note that the inequality sign cannot be used.

Table 13.5.2 Operators

Operator

Meaning

EQ Equal to(=)

NE Not equal to(0)

GT Greater than(>)

GE Greater than or equal to(y)

LT Less than(<)

LE Less than or equal to(x)

The sample program below finds the total of numbers 1 to 10.

O9500;

#1=0; Initial value of the variable to hold the sum. . . . . . . . . . . . . . . . .

#2=1; Initial value of the variable as an addend. . . . . . . . . . . . . . . . .

N1 IF[#2 GT 10] GOTO 2; Branch to N2 when the addend is greater than .

#1=#1+#2; Calculation to find the sum. . . . . . . . . . . . .

#2=#2+1; Next addend. . . . . . . . . . . . . .

GOTO 1; Branch to N1. . . . . . . . . . . . . . .

N2 M30; End of program. . . . . . . . . . . . . . . .

13.5.2

Conditional Branch

(IF Statement)

IF[<conditional

expression>]GOTOn

IF[<conditional

expression>]THEN

Explanations

D Conditional expression

D Operators

Sample program
