OPERATION

11. SETTING AND DISPLAYING DATA

B–63664EN/02

708

This value is incremented by one when M02, M30, or an M code specified

by parameter 6710 is executed. This value cannot be set on this screen.

Set the value in parameter 6712.

It is used for setting the number of machined parts required.

When the “0” is set to it, there is no limitation to the number of parts.

Also, its setting can be made by the parameter (NO. 6713).

This value is incremented by one when M02, M30, or an M code specified

by parameter 6710 is executed. The value can also be set by parameter

6711. In general, this value is reset when it reaches the number of parts

required. Refer to the manual issued by the machine tool builder for

details.

Displays the total time which the power is on. This value cannot be set

on this screen but can be preset in parameter 6710.

Indicates the total run time during automatic operation, excluding the

stop and feed hold time.

This value can be preset in parameter 6751 or 6752.

Displays the total time taken by cutting that involves cutting feed such as

linear interpolation (G01) and circular interpolation (G02 or G03). This

value can be preset in parameter 6753 or 6754.

This value can be used, for example, as the total time during which coolant

flows. Refer to the manual issued by the machine tool builder for details.

Indicates the run time of one automatic operation, excluding the stop and

feed hold time. This is automatically preset to 0 when a cycle start is

performed at reset state. It is preset to 0 even when power is removed.

Displays the current date and time. The date and time can be set on this

screen.

When the command of M02 or M30 is executed, the total number of

machined parts and the number of machined parts are incremented by one.

Therefore, create the program so that M02 or M30 is executed every time

the processing of one part is completed. Furthermore, if an M code set

to the parameter (NO. 6710) is executed, counting is made in the similar

manner. Also, it is possible to disable counting even if M02 or M30 is

executed (parameter PCM (No. 6700#0) is set to 1). For details, see the

manual issued by machine tool builders.

Negative value cannot be set. Also, the setting of “M” and “S” of run time

is valid from 0 to 59.

Negative value may not be set to the total number of machined parts.

Neither negative value nor the value exceeding the value in the following

table can be set.

Item Maximum value Item Maximum value

Year 2085 Hour 23

Month 12 Minute 59

Day 31 Second 59

Display items

D PARTS TOTAL

D PARTS REQUIRED

D PARTS COUNT

D POWER ON

D OPERATING TIME

D CUTTING TIME

D FREE PURPOSE

D CYCLE TIME

D DATA and TIME

Limitations

D Usage

Restrictions

D Run time and part count

settings

D Time settings
