PROGRAMMING18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

346

15090 Minimum power specification value

[Data unit] W

[Data range] 0 to 7000

Minimum clamp value for the power specification value that corresponds

to Mmin. If the power specification value calculated from the current

feedrate is less than the value set for this parameter, clamping is performed

with this value.

15091 Minimum pulse frequency

[Data unit] Hz

[Data range] 5 to 2000

Minimum clamp value for the pulse frequency that corresponds to Mmin

in Fig.18.3. If the frequency calculated from the current feedrate is less

than the value set for this parameter, clamping is performed with this

value.

15092 Minimum pulse duty

[Data unit] %

[Data range] 0 to 100

Minimum clamp value for the pulse duty that corresponds to Mmin in

Fig.18.3. If the duty calculated from the current feedrate is less than the

value set for this parameter, clamping is performed with this value.

15094 Power control filter time constant

[Unit of data ] ms

[Valid data range] 8 to 32767

This parameter specifies a time constant for the primary delay filter used

to delay the power command for synchronization with machine feed.

The primary delay filter is expressed as follows:

+ O

n–1

) (I

–O

n–1

)

Ts: 8 ms (sampling time)

Tc: To be set in this parameter (time constant)

15095 Allowable variation in power control speed

[Unit of data ] mm/min

[Valid data range] 0 to 255

The calculated feedrate slightly fluctuates also in a steady state, and the

data items (specified power, pulse frequency, and pulse duty) calculated

based on the feedrate also fluctuate. To prevent these unnecessary

fluctuations, specify the width of a dead zone for feedrate fluctuations.
