OPERATION8. DATA INPUT/OUTPUT B–63664EN/02
For the program screen
1 Place the CNC in the EDIT mode.
2 Press the function key
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [PRGRM] soft key. The program screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [READ] soft key.
8 Type the O number of an NC program to be input, with the MDI keys.
9 Press the [EXEC] soft key.
10 During input, “INPUT” blinks in the lower–right corner of the screen.
1 If the CNC memory holds an NC program that has the same
O number as that of an NC program to be input, the NC
program in the CNC memory is overwritten when bit 2 of
parameter No. 3201 is set to 1.
2 If an NC program is input when bit 0 of parameter No. 3201
is set to 1, all NC programs in the CNC memory are
automatically deleted before NC program input.
The valid O number of a file to be input to the CNC memory
is Oxxxx (with xxxx representing a number) only.
