OPERATION

B–63664EN/02

6. SAFETY FUNCTIONS

547

When a stroke limit check prior to movement is performed, whether to

check the movement performed by a G31 (skip) block can be determined

using NPC (bit 2 of parameter No. 15600).

If machine lock is applied at the start of movement, no stroke limit check

made before movement is performed.

When a program is restarted, an alarm is issued if the restart position is

within a inhibited area.

When the execution of a block is restarted after manual intervention

following a feed hold stop, no alarm is issued even if the end point

following a manual intervention is within a inhibited area.

If a block consisting of multiple operations is executed, an alarm is issued

at the start point of any operation whose end point falls within a inhibited

area.

In simple synchronous control, only the master axis is checked; no slave

axes are checked.

In three–dimensional coordinate conversion mode, no check is made.

No check is performed while drawing is being performed as part of

dynamic graphic display (only drawing (no machining) is being

performed).

No check is made for a movement based on PMC axis control.

No check is made for a movement based on high–speed, high–precision

contour control (HPCC).

Number Message Contents

4700 PROGRAM ERROR

(OT +)

The value specified in the X-axis move com-

mand exceeded the positive value of stored

stroke limit 1. (Advance check)

4701 PROGRAM ERROR

(OT –)

The value specified in the X-axis move com-

mand exceeded the negative value of stored

stroke limit 1. (Advance check)

4702 PROGRAM ERROR

(OT +)

The value specified in the Y-axis move com-

mand exceeded the positive value of stored

stroke limit 1. (Advance check)

4703 PROGRAM ERROR

(OT –)

The value specified in the Y-axis move com-

mand exceeded the negative value of stored

stroke limit 1. (Advance check)

4704 PROGRAM ERROR

(OT +)

The value specified in the Z-axis move com-

mand exceeded the positive value of stored

stroke limit 1. (Advance check)

4705 PROGRAM ERROR

(OT –)

The value specified in the Z-axis move com-

mand exceeded the negative value of stored

stroke limit 1. (Advance check)

Explanations

Limitations

D Machine lock

D Program restart

D Manual intervention

following a feed hold

stop

D A block consisting of

multiple operations

D Simple synchronous

control

D Three–dimensional

coordinate conversion

D Drawing

D PMC axis control

D High–speed

high–precision contour

control (HPCC)

Alarm
