PROGRAMMING

19. THREE–DIMENSIONAL

CUTTING FUNCTION

B–63664EN/02

389

Spatial corner rounding automatically inserts an arc of the specified

radius into the corner made by two linear movements in space.

G33 G01

X__Y__Z__A__B__R__F__;

X__Y__Z__A__B__;

R__;

X__Y__Z__A__B__;

G34;

Table 19.3 Explanation of the Command Format

Command

Explanation

G33 Starts the spatial corner rounding mode.

G34 Stops the spatial corner rounding mode.

G01 Linear interpolation

X_ Amount of travel to the end point on the X–axis

Y_ Amount of travel to the end point on the Y–axis

Z_ Amount of travel to the end point on the Z–axis

A_ Amount of travel to the end point on the A–axis

B_ Amount of travel to the end point on the B–axis

R_ Specifies the radius of an arc.

F_ Feedrate

G33 specifies spatial corner rounding mode while G34 cancels the mode.

When a one–shot G code is issued in the G33 mode, the spatial corner

rounding mode is canceled.

Use G01 to issue a move command in G33 mode.

If a G code in group 01 other than G01 is issued in G33 mode, an alarm

occurs.

Use R to specify the radius of an arc to be inserted.

When no R command is specified in the block in which G33 is specified,

the nozzle moves linearly.

When only the radius of an arc is specified in a block, an arc is inserted

into the corner between the blocks before and after that block.

When an R command is specified following X, Y, and Z commands in a

block, an arc is inserted into the corner between that block and the next

block.

19.3

SPATIAL CORNER

ROUNDING

(G33 AND G34)

Format

Explanations

D Starting and stopping

spatial corner rounding

mode

D Move command in

spatial corner rounding

mode

D Specifying the radius of

an arc
