OPERATIONB–63664EN/02 11. SETTING AND DISPLAYING DATA
677
The reading on the load meter can be displayed for each servo axis and
the serial spindle by setting bit 5 (OPM) of parameter No. 3111 to 1.
Procedure for displaying the operating monitor
1 Press function key
POS
to display a current position display screen.
2 Press the continuous–menu key
.
3 Press soft key
[MONI].
X : * * * 80% S1 : 201%
Y : * * * * * 0% (SPEED METER RPM)
Z : * * * * * 0% S1 : * * * 1500
OPERATING MONITOR O0001 N00001
(LOAD METER)
[
MEM STRT MTN *** 09:06:35
[ MONI ] [ ] [ ] [ ] [ (OPRT) ]
PART COUNT 5
RUN TIME 0H15M CYCLE TIME 0H 0M38S
ACT.F 3000 MM/M
The reading on the load meter can be displayed for up to eight servo axes
by setting parameters Nos. 3151 to 3158.
When all these parameters are set to 0, data is displayed only to the 3rd
axis.
The bar graph for the load meter shows load up to 200% (only a value is
displayed for load exceeding 200%).
The reading on the load meter depends on servo parameter No. 2086.
If the value of a load meter exceeds 100%, the bar graph turns purple.
11.1.8
Operating Monitor
Display
Procedure
Explanations
D Display of the servo axes
D Unit of graph
D Load meter
D Color of graph
