OPERATION8. DATA INPUT/OUTPUT B–63664EN/02
570
All pitch error compensation data are output in the defined format from
the memory of the CNC to a floppy or NC tape.
Outputting Pitch Error Compensation Data
1 Make sure the output device is ready for output.
2 Specify the punch code system (ISO or EIA) using a parameter.
3 Press the EDIT switch on the machine operator’s panel.
4 Press function key
SYSTEM
.
5 Press the rightmost soft key
(next–menu key) and press chapter
selection soft key
[PITCH].
6 Press soft key
[(OPRT)].
7 Press rightmost soft key
(next–menu key).
8 Press soft keys [PUNCH] and [EXEC].
All parameters are output in the defined format.
Output format is as follows:
N 10000 P ;. . .
N 11023 P ;. . . . . .
N : Pitch error compensation point No. +10000. . .
P : Pitch error compensation data. . .
When the floppy disk directory display function is used, the name of the
output file is
“PITCH ERROR”.
8.6.4
Outputting Pitch Error
Compensation Data
Procedure
Explanations
D Output format
D Output file name
