PROGRAMMING16. HIGH SPEED CUTTING FUNCTIONS
B–63664EN/02
292
⋅ High–precision contour control
⋅ Axis control by the PMC
(Bits 4 (G8R) and 3 (G8C) of parameter No. 8004 can be set to also use
this function in the look–ahead control mode.)
⋅ Single direction positioning
⋅ Polar coordinate command
⋅ Helical interpolation
⋅ Program restart
⋅ External deceleration
⋅ Simple synchronous control
⋅ Sequence number comparison and stop
⋅ Position switch
(Bit 3 (PSF) of parameter No. 6901 can be set to also use this function
in the advanced preview control mode. When this parameter is set to
1, the time of signal output varies. This may require ladder program
modification
and other action.)
⋅ Custom macro B
⋅ Optional–angle chamfering/corner rounding
⋅ Inch/metric conversion
⋅ Programmable mirror image
⋅ Automatic corner override
(Only the internal circular cutting feedrate change is valid.)
⋅ Scaling
⋅ Coordinate system rotation
⋅ Workpiece coordinate system
⋅ Figure copy
⋅ Workpiece coordinate system preset
⋅ Cutter compensation C
⋅ Corner circular interpolation
⋅ Tool offset
⋅ Graphic display
⋅ Dynamic graphic display
