PROGRAMMING

4. INTERPOLATION FUNCTIONS

B–63664EN/02

In a block specifying P1 to P4 after G31, the multi–step skip function

stores coordinates in a custom macro variable when a skip signal (4–point

or 8–point) is turned on.

Parameters No. 6202 to No. 6205 can be used to select a 4–point or

8–point skip signal. One skip signal can be set to match multiple Pn or

Qn (n=1,2,3,4) as well as to match a Pn or Qn on a one–to–one basis.

Parameters DS1 to DS8 (No. 6206 #0A#7) can be used for dwell.

Move command

G31 IP __ F __ P __ ;

G04 X (U, P)__ (Q__)

;

Dwell

_ : End point

F_ : Feedrate

P_ : P1–P4

X(U, P)_ : Dwell time

Q_ : Q1 – Q4

Multi–step skip is caused by specifying P1, P2, P3, or P4 in a G31 block.

For an explanation of selecting (P1, P2, P3, or P4), refer to the manual

supplied by the machine tool builder.

Specifying Q1, Q2, Q3, or Q4 in G04 (dwell command) enables dwell

skip in a similar way to specifying G31. A skip may occur even if Q is

not specified. For an explanation of selecting (Q1, Q2, Q3, or Q4), refer

to the manual supplied by the machine tool builder.

Parameter Nos. 6202 to 6205 can be used to specify whether the 4–point

or 8–point skip signal is used. Specification is not limited to one–to–one

correspondence. It is possible to specify that one skip signal correspond

to two or more Pn’s or Qn’s (n=1, 2, 3, 4). Also, bits 0 (DS1) to 7 (DS8)

of parameter No. 6206 can be used to specify dwell.

CAUTION

Dwell is not skipped when Qn is not specified and

parameters DS1–DS8 (No. 6206#0–#7) are not set.

4.11

MULTI–STEP SKIP

(G31)

Format

Explanations

D Correspondence to skip

signals
